APC Easy UPS On-Line SRV 1000VA Rackmount 230V with Rail Kit SRV1KRIRK

The APC Easy UPS On-Line SRV 1000VA Rackmount 230V with Rail Kit is a double-conversion online UPS designed to provide continuous, clean, and stable power protection for servers, networking equipment, storage systems, telecommunications equipment, and other critical IT devices. With a 1000VA / 800W capacity, pure sine wave output, zero transfer time, automatic voltage regulation, and a rackmount design, the SRV1KRIRK helps protect connected equipment from power outages, voltage fluctuations, electrical noise, and other power disturbances. The included rail kit supports convenient installation in compatible server racks, making this UPS suitable for professional data centers, network cabinets, server rooms, and IT infrastructure.

Product Features

Double-Conversion Online UPS

The APC SRV1KRIRK uses double-conversion online technology to continuously regulate incoming power and provide stable output to connected equipment. This provides a high level of power protection for servers and other sensitive IT equipment.

1000VA / 800W Capacity

The UPS provides a 1000VA capacity with an 800W power rating, making it suitable for protecting servers, network switches, storage equipment, communication devices, and other compatible IT loads.

Pure Sine Wave Output

The SRV1KRIRK delivers pure sine wave output, including during battery operation. This provides clean and stable power for sensitive electronic and IT equipment.

Zero Transfer Time

Online double-conversion technology provides zero transfer time between utility power and battery operation. This helps connected equipment continue operating without the switching delay associated with conventional UPS technologies.

Rackmount Design

The SRV1KRIRK is designed for installation in compatible server racks and network cabinets. Its rackmount configuration helps save floor space and allows the UPS to be integrated into centralized IT infrastructure.

Included Rail Kit

The included rail kit supports secure rack installation and makes it easier to mount the UPS within a compatible rack enclosure. This is particularly useful for server rooms, network cabinets, and data center environments.

Automatic Voltage Regulation

The UPS continuously regulates incoming power to help maintain stable output voltage. This helps protect connected equipment from potentially damaging voltage variations.

LCD Status Display

An integrated LCD interface provides important operating information, including power conditions, battery status, load level, and UPS operating status. This allows users to monitor the system locally.

ECO Energy-Saving Mode

ECO mode provides an energy-efficient operating option when suitable power conditions are available. This can help reduce energy consumption in applications where full online power conditioning is not required.

Intelligent Battery Management

Temperature-compensated battery charging helps manage battery charging according to operating conditions. This supports reliable battery performance and helps optimize battery service life.

USB and RS-232 Communication

USB and RS-232 interfaces provide communication between the UPS and compatible computers or management systems. These connections can support monitoring and UPS management functions.

Intelligent Card Slot

The UPS includes an intelligent card slot for compatible management accessories. An optional network management card can provide additional remote monitoring and management capabilities for supported installations.

Multiple IT Applications

The APC SRV1KRIRK is suitable for servers, network switches, storage devices, telecommunications equipment, security systems, and other critical electronics that require continuous power protection.

Product Specifications

• • Brand: APC by Schneider Electric
  • Product Series: Easy UPS On-Line
  • Model: SRV1KRIRK
  • Product Type: Rackmount Online UPS
  • UPS Topology: Double-conversion online
  • Rated Capacity: 1000VA
  • Rated Power: 800W
  • Nominal Input Voltage: 230V
  • Nominal Output Voltage: 230V
  • Configurable Output Voltage: 220V / 230V / 240V
  • Output Waveform: Pure sine wave
  • Output Frequency: 50/60 Hz
  • Input Frequency: 40 to 70 Hz
  • Transfer Time: Zero
  • Output Connections: 3 x IEC 60320 C13
  • Input Connection: IEC 60320 C14
  • Bypass: Internal automatic and manual bypass
  • Display: LCD
  • Operating Modes: Online and ECO
  • Battery Type: Maintenance-free sealed lead-acid
  • Battery Voltage: 24V
  • Battery Recharge Time: Approximately 4 hours
  • Communication Interfaces: USB and RS-232
  • Intelligent Card Slot: Supported
  • Network Management: Supported through a compatible optional management card
  • Rackmount Installation: Supported
  • Rail Kit: Included
  • Form Factor: Rackmount
  • Primary Applications: Servers, network equipment, storage systems, telecommunications equipment, security systems, and other sensitive IT equipment
  • Installation: Rack-mounted installation with included rail kit
